012126 IDA Platinum Electrode
Brand: CH Instruments | Category: Nanotechnology
The platinum version of the interdigitated array electrode, catalogued by CH Instruments as 012126. Its published geometry matches the rest of the IDA family: 65 pairs of generator and collector bands of 10 micron width, 5 micron interval and 2 mm length. Redox cycling between the interdigitated bands is what raises the measured signal, and the 011066 cable kit provides the connection.
Technical Specifications
| Parameter | Value |
|---|---|
| Electrode material | Platinum |
Published manufacturer data for the listed model or variants. Confirm the exact configuration, accessories and test conditions in the quotation. Checked 2026-09-29.
Confirm your configuration
Share the details you know so we can prepare a comparable, itemised offer.
- Exact host instrument/model and intended experiment
- Mechanical, electrical, optical or material compatibility as applicable
- Required dimensions/range, connectors, included parts and quantity
Get a Quote
Request an itemised quotation covering the proposed configuration, availability, lead time and agreed supply and support scope.
Useful details to share
- Materials, sample dimensions and process or measurement goal
- Required performance and existing instrument interfaces
Share what you know. You can start with your name and a phone number or email; final specifications can follow.
Not sure which configuration you need? Help me choose
Contact Vvon Technologies Limited about CH Instruments equipment requirements in Bangladesh.
Phone: +8801805987890 | Email: info@vvon.com.bd
