BDAS: Data Acquisition System and Sensors
Brand: EDIBON | Category: Scientific & Laboratory Equipment
Designed to monitor the measurements of each "FME" type unit from a computer (PC), BDAS can check readings across any unit, including revolutions given by the water pump or the torque, differential pressures for Bernoulli theorems, pressure measurements, flow measurements, etc.
Selected manufacturer specifications
| Parameter | Value |
|---|---|
| Platform | Data acquisition for selected FME experiments |
| Pressure-sensor option | 0–100 psi (0–7 bar) |
| High-flow sensor option | 5–150 L/min |
| Low-flow sensor option | 1.5–30 L/min |
| Acquisition interface | National Instruments PCI Express |
| Base-unit dimensions | 300 × 550 × 1,200 mm approx. |
Only sensors matching the purchased FME units are included. Pressure and flow ranges describe the individual sensor options, not every supplied BDAS package. Confirm the selected sensors, adapters, compatible computer and experiment configuration. Checked 2026-09-29.
Manufacturer reference document (opens in a new tab)
Confirm your configuration
Share the details you know so we can prepare a comparable, itemised offer.
- Fluid mechanics experiments, syllabus and number of student workstations
- Required base unit, modules, sensors, control/data-acquisition software and accessories
- Bench/floor space, utilities, practical manuals and faculty training
Get a Quote
Request an itemised quotation covering the proposed configuration, availability, lead time and agreed supply and support scope.
Useful details to share
- Intended application, process or teaching activity
- Required capability and equipment it must work with
Share what you know. You can start with your name and a phone number or email; final specifications can follow.
Not sure which configuration you need? Help me choose
Contact Vvon Technologies Limited about EDIBON equipment requirements in Bangladesh.
Phone: +8801805987890 | Email: info@vvon.com.bd
