Cardiac Trigger Monitor with patient cable and lead wires
Brand: MiE GmbH | Category: Nuclear Medicine & Imaging
An ECG trigger for synchronised application in nuclear and molecular imaging such as gated SPECT and MUGA studies. MiE describe the operation as intuitive with a reliable cardiac trigger, and the pulse width is user selectable at 1 ms, 50 ms, 100 ms or 150 ms. The front panel is a 6.5 in (16.5 cm) active matrix TFT colour touch screen at 640 x 480 resolution. A four lead patient cable with a 6 PIN AAMI standard connector and a set of four lead wires are published alongside the monitor.
Selected manufacturer specifications
| Parameter | Value |
|---|---|
| Display | 6.5-inch colour touch screen |
| Display resolution | 640 × 480 pixels |
| Dimensions (H × W × D) | 19.02 × 20.17 × 13.16 cm |
| Weight | 1.8 kg |
| Line frequency | 50 / 60 Hz |
Selected dimensions and display data from MiE. Confirm the exact monitor model, ECG gating interface, patient cable and lead set; this table does not establish compatibility with every imaging system. Checked 2026-09-29.
Confirm your configuration
Share the details you know so we can prepare a comparable, itemised offer.
- Intended department workflow, radionuclide and equipment configuration
- Required range, sensitivity/geometry and compatible system interfaces
- Site requirements, physics acceptance, training and service scope
Get a Quote
Request an itemised quotation covering the proposed configuration, availability, lead time and agreed supply and support scope.
Useful details to share
- Department workflow and intended equipment use
- Required configuration and existing system interfaces
Share what you know. You can start with your name and a phone number or email; final specifications can follow.
Not sure which configuration you need? Help me choose
Contact Vvon Technologies Limited about MiE GmbH equipment requirements in Bangladesh.
