CTIQ
Brand: Leeds Test Objects | Category: Nuclear Medicine & Imaging
A CT image quality phantom built as a PMMA cylinder with recesses for test inserts, sized to nest inside the TO CTDI body phantom. It covers geometric distortion, CT number, MTF, resolution, slice profile and table movement accuracy in one setup.
Technical Specifications
| Parameter | Value |
|---|---|
| Specification | PMMA cylinder with recesses to house test inserts |
| Specification | Designed to nest within the TO CTDI body phantom |
| Tests | geometric distortion, CT number (HU), artefacts, MTF, spatial resolution, contrast resolution |
| Tests | slice profile, slice incrementation, table movement accuracy |
| Specification | Noise and uniformity available when nested in the CTDI phantom |
Get a Quote
Request an itemised quotation covering the proposed configuration, availability, lead time and agreed supply and support scope.
Useful details to share
- Department workflow and intended equipment use
- Required configuration and existing system interfaces
Share what you know. You can start with your name and a phone number or email; final specifications can follow.
Not sure which configuration you need? Help me choose
Contact Vvon Technologies Limited about Leeds Test Objects equipment requirements in Bangladesh.
Phone: +8801805987890 | Email: info@vvon.com.bd
Back to Nuclear Medicine & Imaging
More from Radiology & Radiotherapy QA Phantoms
- MicroCT set
A set of test objects for assessing image quality on pre-clinical microCT systems. It covers bone density, low contrast, reconstruction artefacts, uniformity and noise, point spread function and dose index in a common cylindrical format.
- CTAEC-50
A CT automatic exposure control phantom using six reconfigurable PMMA ellipses of 50 mm thickness. It is used for constancy testing of CT AEC systems where a coarser step size than the CTAEC-25 is sufficient.
- Mouse Phantom
A tissue mimicking mouse shaped phantom for demonstrating and assessing image quality on pre-clinical microCT scanners. It contains tissue mimicking skeleton, lung and soft tissue, with a choice of soft tissue CT number.
