ECAT SCINTRON UPGRADE
Brand: MiE GmbH | Category: Nuclear Medicine & Imaging
An upgrade that pairs an installed ECAT positron emission tomography scanner with current SCINTRON acquisition, processing, quantification and viewing hardware and software. It adds 3D acquisition with CASCADE scatter correction and list mode acquisition for coronary flow reserve.
Technical Specifications
| Parameter | Value |
|---|---|
| ECAT EXACT 47 | BGO, 47 planes, 162 mm axial and 583 mm transversal FOV |
| ECAT EXACT HR+ | BGO, 63 planes, 155 mm axial and 583 mm transversal FOV |
| ECAT ACCEL | LSO, 47 planes, 162 mm axial and 583 mm transversal FOV |
| Specification | 3D acquisition with CASCADE scatter correction |
| Specification | List mode acquisition for coronary flow reserve |
| Specification | Interface to Invia 4DM and Cedars Sinai QPET quantification |
