Coarto Force Gauge
Brand: Leeds Test Objects | Category: Nuclear Medicine & Imaging
A digital force gauge that measures the breast compression force applied by a mammography system. It has a dynamic display and a peak hold display, so the maximum force reached during a compression cycle can be read afterwards, and it is supplied with a compressible rubber block.
Technical Specifications
| Parameter | Value |
|---|---|
| Specification | Maximum measurement 30 kg (300 N) |
| Specification | Accurate to 5 g |
| Specification | Dynamic display and peak hold display |
| Specification | Supplied with a compressible rubber block |
| Specification | Conforms to IPEM Report 89 and EUREF 2a.2.1.4 |
