CODITEL: Telephony Systems Unit
Brand: EDIBON | Category: Scientific & Laboratory Equipment
A unit for studying digital switching in telephony networks. It reproduces a time switch with one inlet and one outlet PCM path, so students can follow connection set up, channel assignment and traffic management in a digital exchange.
Technical Specifications
| Parameter | Value |
|---|---|
| Specification | Follows the recommendations of CCITT for digital commutation systems |
| Specification | Temporal commutator supporting up to fifteen complete internal communications |
| Standard MIC system of 32 channels | 30 for voice, 2 for signalling and synchronism |
| Specification | Codec at 8 kHz sample rate, 8 bits per sample, 64 kbit/s per channel, 2.048 Mbit/s frame |
| Specification | Two subscriber lines with discrete elements and two with SLIC integrated circuits |
| Specification | Analog board plus digital board based on FPGA technology |
