FME12: Series/Parallel Pumps
Brand: EDIBON | Category: Scientific & Laboratory Equipment
FME12 is a bench module with two centrifugal pumps that can be run singly, in series or in parallel. Head and flow are measured for each arrangement so students can build the combined characteristic curves and see how the duty point changes.
Technical Specifications
| Parameter | Value |
|---|---|
| Centrifugal pump power | 0.37 kW |
| Published pump duty | 30–80 l/min at 20.1–12.8 m head |
| Pump-inlet pressure gauge | −1 to 3 bar |
| Discharge pressure gauges | 0–4 bar |
| Unit dimensions | 500 x 400 x 400 mm approx. |
| Unit weight | 20 kg approx. |
Selected data from the model-specific panel on page 22 of the manufacturer LIFLUBA brochure. Unit dimensions and weights are approximate. The hydraulic bench/feed system and other required elements may be supplied separately; confirm the current model, accessories and complete quotation scope. Checked 2026-09-29.
