Gafchromic custom cuts
Brand: Ashland | Category: Medical Equipment
Ashland describes custom cuts as a service: any Gafchromic film can be cut to the size, shape and specification a department needs, arriving ready for use straight out of the box. Six cuts are currently published with their own product codes, spanning EBT3, MD-V3 and LD-V1 grades in both imperial and metric sizes. Sizes outside the published list are cut to order on request.
Manufacturer-listed cut formats
| Parameter | Value |
|---|---|
| EBT3 Ballcube II, without slit | 2.5 × 2.5 in; 20 pieces; code 932840 |
| EBT3 square option | 3 × 3 in; 30 pieces; code 907414 |
| EBT3 metric square option | 15 × 15 cm; 25 pieces; code 828202 |
| MD-V3 square option | 2.5 × 2.5 in; 20 pieces; code 828212 |
| LD-V1 square option | 1.5 × 1.5 in; 20 pieces; code 972418 |
| LD-V1 rectangular option | 4 × 2.5 in; 20 pieces; code 972419 |
Selected cut formats listed by Ashland. Film grade, cut dimensions and quantity identify different items; confirm the exact code and phantom compatibility for the quotation. Checked 2026-09-29.
Confirm your configuration
Share the details you know so we can prepare a comparable, itemised offer.
- Imaging modality or beam, energy range and intended QA test
- Phantom/dosimeter geometry, detector/readout compatibility and calibration needs
- Required test inserts, analysis software, certificates and acceptance criteria
Get a Quote
Request an itemised quotation covering the proposed configuration, availability, lead time and agreed supply and support scope.
Useful details to share
- Clinical, training or facility application
- Required configuration, accessories and existing equipment
Share what you know. You can start with your name and a phone number or email; final specifications can follow.
Not sure which configuration you need? Help me choose
Contact Vvon Technologies Limited about Ashland equipment requirements in Bangladesh.
Phone: +8801805987890 | Email: info@vvon.com.bd
