Guarded Insert for PPMS
Brand: Lake Shore | Category: Nanotechnology
This insert carries van der Pauw and Hall bar samples inside a PPMS cryostat, with a fully guarded signal path from instrument to sample. Used with the M91 FastHall controller it measures resistance from 10 milliohms to 200 gigaohms between 1.9 K and 400 K. An integrated Cernox sensor reads sample temperature.
Technical Specifications
| Parameter | Value |
|---|---|
| Resistance range | 10 mΩ to 200 GΩ |
| Operating temperature range | 1.9 K to 400 K |
| Triaxial center conductor leakage current | <500 fA at 10 V |
| Maximum current per pin | 100 mA |
| Mobility | 0.001 cm2/(V s) to 10^6 cm2/(V s) |
| Temperature sensor | integrated Cernox temperature sensor local to sample |
