INNOVA Series
Brand: Coherent | Category: Scientific & Laboratory Equipment
INNOVA are argon and krypton ion lasers producing output on many wavelengths, including high power ultraviolet lines. Small and large frame models are offered in OEM and turnkey form, with multi-line powers as high as 25 W from the ultraviolet through to the infrared.
Technical Specifications
| Parameter | Value |
|---|---|
| INNOVA 70C | small frame, 5 W maximum multiline output |
| INNOVA 90C | small frame, 6 W maximum multiline output |
| INNOVA 300C | small frame, 8 W maximum multiline output, 0.75 W multiline UV |
| INNOVA Sabre | large frame, 25 W maximum multiline output, 7 W multiline UV |
| INNOVA FreD | intracavity frequency doubling, up to 1 W CW from 229 to 264 nm, 20 W maximum multiline output |
