iXon EMCCD Cameras for Microscopy & Life Science
Brand: Oxford Instruments | Category: Nanotechnology
Andor's iXon platform is a dedicated ultrasensitive EMCCD camera family engineered to draw the best from electron multiplying CCD technology across every critical performance parameter. Two sensor formats are offered, the 1024 x 1024 iXon 888 for field of view, sensitivity and speed, and the 512 x 512 iXon 897 for sensitivity and speed, each available in Ultra and Life platforms. iXon Ultra adds a conventional CCD amplifier, integrated shutter, CameraLink direct data access, single photon counting modes and cooling to -100 °C, while iXon Life is aimed exclusively at fluorescence microscopy with cooling to -80 °C. Both platforms are compatible with SRRF-Stream + real time super-resolution, which typically improves resolution by 2 to 6 fold, giving 50-150nm final resolution.
Model specifications
Compare the named models or configurations. Confirm options and included accessories in your quotation.
| Models | iXon 888 | iXon 897 |
|---|---|---|
| Core attributes | Field of view, sensitivity and speed | Sensitivity and speed |
| Sensor format | 1024 x 1024 | 512 x 512 |
| Sensor diagonal | 18.8 mm | 11.6 mm |
| QE Options | BV (Life) or BV, EX2, UVB (Ultra) | BV (Life) or BV, EX2, UVB (Ultra) |
| Pixel Size | 13 µm | 16 µm |
| Frame Rate | 26 fps (670 fps with 128 x 128 Crop Mode) | 56 fps (595 fps with 128 x 128 Crop Mode) |
| Read Noise | < 1 e- with EM Gain | < 1 e- with EM Gain |
| Pixel well depth | 80,000 e- | 180,000 e- |
| Interface | USB 3.0 | USB 2.0 |
Manufacturer catalogue checked 2026-09-29.
Selected manufacturer comparison data, with each model retained in its own column. Performance depends on the chosen sensor, optics and operating conditions. Confirm the exact model and options in the current quotation.
