MEAL: Cam Analysis Unit
Brand: EDIBON | Category: Scientific & Laboratory Equipment
MEAL is used for the dynamic analysis of cams. Interchangeable cam profiles drive a follower whose lift is recorded against cam angle, and follower jump can be studied by varying the running speed and the spring load.
Technical Specifications
| Parameter | Value |
|---|---|
| Dimensions | 750 x 500 x 500 mm approx |
| Weight | 70 Kg approx |
| Power | 250 W approx |
| Velocity | 0 to 670 rpm approx |
| Speed sensor, range | 0 to 1000 rpm |
| Three interchangeable springs with different constants. Values | 5.026 N/mm, 2.601 N/mm and 0.613 N/mm |
