UVblade
Brand: Coherent | Category: Scientific & Laboratory Equipment
UVblade uses 308 nm excimer pulses to detach polymer based flexible displays from rigid glass carriers in a laser lift-off process. Three models cover beam lengths of 380 mm, 750 mm and 1250 mm with a top hat line beam and a large depth of focus.
Technical Specifications
| Parameter | Value |
|---|---|
| Wavelength | 308 nm |
| UVblade 380 | 580 mJ pulse energy, 200 Hz, 380 mm beam length |
| UVblade 750 | 1000 mJ or 2000 mJ pulse energy, 600 Hz, 750 mm beam length |
| UVblade 1250 | 2000 mJ pulse energy, 600 Hz, 1250 mm beam length |
| Line beam homogeneity | 1.8 % (2 sigma) |
| Depth of focus | +/-200 microns |
