LineBeam
Brand: Coherent | Category: Scientific & Laboratory Equipment
LineBeam systems deliver line beam profiles for excimer laser annealing of low temperature polysilicon backplanes on large display substrates. Line lengths run from 750 mm to 1500 mm at 308 nm or 355 nm, with top hat profiles along both axes.
Technical Specifications
| Parameter | Value |
|---|---|
| Line length options | 750, 1000, 1300 and 1500 mm |
| Beam profile type | top-hat along both axes |
| Depth of focus | +/-150 um at 750 mm, +/-120 um at 1000, 1300 and 1500 mm |
| Long axis homogeneity | 0.6 % (2 sigma) |
| Short axis homogeneity | 0.8 % (2 sigma) |
| Wavelength | 308 nm or 355 nm, panel sizes up to Gen 10.5 |
