Xplore
Brand: Oxford Instruments | Category: Nanotechnology
Xplore is a compact energy dispersive X-ray detector for routine microanalysis in the SEM. It uses the same X4 electronics as the larger Ultim Max Infinity detectors in a smaller package, with motorised insertion and extra cooling removed to reduce parts and allow in field repair.
Plan your specification
Specify Xplore for your routine SEM workload
Xplore is positioned by Oxford Instruments for routine EDS in the SEM. Confirm the installed configuration and performance against the specimens your laboratory will analyse.
- Microscope compatibility
- Provide the exact SEM model, ports, stage, other detectors and computer details. Request written confirmation of mechanical fit, interfaces and installation responsibilities.
- Routine elements, sample preparation and expected analysis time
- Ask for representative spectra and maps with the acquisition conditions recorded. Include the quantitative method and reporting functions required.
- Software and acceptance scope
- List licences, data exports, workstation, training and the sample demonstration in the offer. Agree what will be checked after installation and the support terms.
Product documentation
Technical Specifications
| Parameter | Value |
|---|---|
| Sensor sizes | 15 mm2, 30 mm2 and 65 mm2 |
| Mapping count rates | greater than 1,000,000 cps |
| Mn Ka resolution guaranteed | better than 129 eV at 100 kcps for all sensor sizes |
| Specification | Quantitative analysis at count rates greater than 100 kcps |
| Specification | Uses X4 electronics from the Ultim Max Infinity range |
Get a Quote
Request an itemised quotation covering the proposed configuration, availability, lead time and agreed supply and support scope.
Useful details to share
- SEM model, port and existing detector configuration
- Sample types, target elements and required outputs
Share what you know. You can start with your name and a phone number or email; final specifications can follow.
Not sure which configuration you need? Help me choose
Contact Vvon Technologies Limited about Oxford Instruments equipment requirements in Bangladesh.
Phone: +8801805987890 | Email: info@vvon.com.bd
