AEL-TI-02: Distribution Transformer with Motor Regulation Application
Brand: EDIBON | Category: Scientific & Laboratory Equipment
Covers distribution transformers and their part in regulating voltage on the medium and low voltage network. The transformer has a motorised tap changer so students can watch regulation act as the load and the supply voltage change.
Technical Specifications
| Parameter | Value |
|---|---|
| Electrical supply | three-phase, 380 VAC to 400 VAC/50 Hz |
| Dimensions | 1000 x 450 x 1000 mm |
| Weight | 30 Kg approx |
| Nominal power | 1 kVA |
| Nominal voltage | 400 VAC |
