ATBB: Aerodynamic Testing Bench
Brand: EDIBON | Category: Scientific & Laboratory Equipment
ATBB is a bench for basic aerodynamic experiments. Air is drawn over interchangeable models so that drag, boundary layer growth, pressure distribution and the flow around bluff and streamlined bodies can be measured.
Technical Specifications
| Parameter | Value |
|---|---|
| Dimensions | 1400 x 820 x 2200 mm approx |
| Weight | 80 Kg approx |
| Power consumption | 0.5 kW |
| Maximum flow rate | 17 m³/min |
| Specification | Nozzle with outlet section of 50 x 100 mm. Maximum speed of the flow at the outlet of the nozzle |
