C-FIBER 780 nm and 1560 nm Femtosecond Fiber Lasers
Brand: ThorLabs | Category: Scientific & Laboratory Equipment
All polarisation maintaining fibre femtosecond sources using Menlo Systems figure 9 mode locking. They reach output in under a minute from a single button and hold a single mode-lock state, for nonlinear microscopy and frequency comb work.
Technical Specifications
| Parameter | Value |
|---|---|
| Centre wavelengths | 780 nm plus or minus 10 nm and 1560 nm plus or minus 20 nm |
| Average output power | greater than 250 mW at 780 nm, greater than 500 mW at 1560 nm |
| Pulse width | less than 100 fs at 780 nm, less than 90 fs at 1560 nm |
| Pulse energy | greater than 2.5 nJ and greater than 5 nJ |
| Repetition rate | 100 MHz, factory set from 50 to 250 MHz with the VARIO option |
| Repetition rate instability | less than 1 ppm over 20 hours at constant temperature |
