DIL L74 HM
Brand: Linseis | Category: Nanotechnology
The DIL L74 HM is a heating microscope for thermo-optical analysis. A high-resolution camera with automated focus records the sample in real time, so melting behaviour, volumetric change and contact angle can be followed. Measurements follow DIN 51730 and ISO 540 among other standards.
Technical Specifications
| Parameter | Value |
|---|---|
| Temperature range | -100 C up to 500 C, RT up to 500/1000/1500/2000 C |
| Measuring system | optical, non contact |
| Accuracy | up to 1 um |
| Field of view | 10 x 14 mm |
| Heating rate | 0.01 to 100 K/min (depends on furnace) |
| Atmosphere | inert, reducing, oxidising, vacuum up to 10-5 mbar (option) |
