DMAM2 Gold
Brand: Leeds Test Objects | Category: Nuclear Medicine & Imaging
The gold contrast detail plate from the DMAM2 set, available on its own for routine threshold contrast scoring on digital mammography systems. It carries 78 details in six sizes across a wide contrast range.
Technical Specifications
| Parameter | Value |
|---|---|
| Specification | 78 threshold contrast details in 6 sizes |
| Specification | Detail diameters 0.1 mm to 2.0 mm |
| Specification | Contrast range 0.489% to 27.56% |
| Specification | Conforms to the European guidelines for quality assurance in breast cancer screening and diagnosis, 4th edition |
| Specification | AutoPIA automatic analysis software available for this phantom |
Get a Quote
Request an itemised quotation covering the proposed configuration, availability, lead time and agreed supply and support scope.
Useful details to share
- Department workflow and intended equipment use
- Required configuration and existing system interfaces
Share what you know. You can start with your name and a phone number or email; final specifications can follow.
Not sure which configuration you need? Help me choose
Contact Vvon Technologies Limited about Leeds Test Objects equipment requirements in Bangladesh.
Phone: +8801805987890 | Email: info@vvon.com.bd
Back to Nuclear Medicine & Imaging
More from Radiology & Radiotherapy QA Phantoms
- PIXMAM
A digital mammography image quality phantom made from a stack of finely toleranced PMMA plates, one of which carries an encapsulated aluminium foil. It is used for AEC checks, detector homogeneity, signal to noise ratio and contrast to noise ratio.
- DMAM2
A full digital mammography phantom set built to the fourth edition European guidelines. It combines a threshold contrast detail plate, filaments, a graded set of PMMA plates, mesh and grid targets, a steel straight edge, a resolution pattern and the filters needed for homogeneity and ghosting tests.
- PIXMAM 3D
A routine image quality phantom for digital breast tomosynthesis. It adds a plate holding twenty five embedded spheres for the Z resolution test to the standard PIXMAM stack, so geometric distortion and image resolution can also be checked.
