PIXMAM
Brand: Leeds Test Objects | Category: Nuclear Medicine & Imaging
A digital mammography image quality phantom made from a stack of finely toleranced PMMA plates, one of which carries an encapsulated aluminium foil. It is used for AEC checks, detector homogeneity, signal to noise ratio and contrast to noise ratio.
Technical Specifications
| Parameter | Value |
|---|---|
| PMMA plates 300 x 240 mm | 1 x 20 mm with encapsulated 99.99% Al foil 0.20 x 10 x 10 mm |
| Specification | Plus 2 x 20 mm, 1 x 10 mm and 1 x 5 mm PMMA plates |
| Specification | Tests AEC, detector homogeneity, SNR and CNR |
| Conforms to NHSBSP pub 604-3 | 2009 and NHSBSP pub 702-1:2007 |
| Specification | Conforms to EUREF 4th edition European Guidelines |
| Specification | AutoPIA automatic analysis software available for this phantom |
Get a Quote
Request an itemised quotation covering the proposed configuration, availability, lead time and agreed supply and support scope.
Useful details to share
- Department workflow and intended equipment use
- Required configuration and existing system interfaces
Share what you know. You can start with your name and a phone number or email; final specifications can follow.
Not sure which configuration you need? Help me choose
Contact Vvon Technologies Limited about Leeds Test Objects equipment requirements in Bangladesh.
Phone: +8801805987890 | Email: info@vvon.com.bd
