DMGT: Dynamic Multistage Gear Train Analysis Unit
Brand: EDIBON | Category: Scientific & Laboratory Equipment
DMGT is used to analyse multistage gear trains under running conditions. Speed and torque are measured at the input and output of each stage so the ratio, transmitted power and efficiency can be obtained across the whole train.
Technical Specifications
| Parameter | Value |
|---|---|
| Dimensions | 730 x 650 x 1500 mm approx |
| Weight | 250 Kg approx |
| Specification | 7 weights of 5 kg |
| Specification | 4 weights of 2.5 kg |
