DT-670 Silicon Diodes
Brand: Lake Shore | Category: Nanotechnology
DT-670 silicon diodes are cryogenic temperature sensors that give a voltage output which varies with temperature. They cover 1.4 K to 500 K in the SD, CU-HT and BR packages and 1.4 K to 420 K in the others, with typical accuracy of +/-12 mK at 4.2 K and +/-35 mK at 300 K.
Technical Specifications
| Parameter | Value |
|---|---|
| Temperature range | 1.4 K to 500 K (SD, CU-HT, BR packages) |
| Temperature range | 1.4 K to 420 K (CU, LR, CY, ET, MT, BO, HR packages) |
| Typical sensor accuracy | +/-21 mK at 1.4 K, +/-12 mK at 4.2 K, +/-34 mK at 77 K |
| Typical sensor accuracy | +/-35 mK at 300 K, +/-54 mK at 500 K |
| Voltage output | 1.64 V at 1.4 K, 1.03 V at 77 K, 0.560 V at 305 K |
| Sensitivity | -12.5 mV/K at 1.4 K, -1.73 mV/K at 77 K, -2.30 mV/K at 305 K |
