ENVIRO-MATRIX Altair
Brand: Semian | Category: Scientific & Laboratory Equipment
Passive gas treatment device for semiconductor process tool effluent, working without fuel gas or other utilities. It draws room air through the existing scrubber or ventilation system, which keeps running cost and maintenance time low.
Technical Specifications
| Parameter | Value |
|---|---|
| Specification | No flammable fuel gases required |
| Specification | Dimensions 30 in long x 23 in tall x 14 in wide |
| Specification | Requires only 100 to 220 CFM of scrubber or ventilation air at 1 in W.C. static pressure |
| Specification | Preventive maintenance takes 15 to 45 minutes |
| Specification | Typical maintenance interval 1 to 3 months |
Get a Quote
Request an itemised quotation covering the proposed configuration, availability, lead time and agreed supply and support scope.
Useful details to share
- Intended application, process or teaching activity
- Required capability and equipment it must work with
Share what you know. You can start with your name and a phone number or email; final specifications can follow.
Not sure which configuration you need? Help me choose
Contact Vvon Technologies Limited about Semian equipment requirements in Bangladesh.
Phone: +8801805987890 | Email: info@vvon.com.bd
