FME01: Jet Impact on Surfaces
Brand: EDIBON | Category: Scientific & Laboratory Equipment
FME01 is used to measure the force produced by a water jet striking a target. Flat, conical and hemispherical targets are fitted in turn and balanced by weights, so the measured force can be compared with the momentum equation.
Technical Specifications
| Parameter | Value |
|---|---|
| Jet diameter | 8 mm |
| Impact surface diameter | 40 mm |
| Impact surfaces | 180° hemispherical; 120° curved; 90° flat |
| Unit dimensions | 250 x 250 x 500 mm approx. |
| Unit weight | 5 kg approx. |
Selected data from the model-specific panel on page 14 of the manufacturer LIFLUBA brochure. Unit dimensions and weights are approximate. The hydraulic bench/feed system and other required elements may be supplied separately; confirm the current model, accessories and complete quotation scope. Checked 2026-09-29.
Manufacturer reference document (opens in a new tab)
Confirm your configuration
Share the details you know so we can prepare a comparable, itemised offer.
- Fluid mechanics experiments, syllabus and number of student workstations
- Required base unit, modules, sensors, control/data-acquisition software and accessories
- Bench/floor space, utilities, practical manuals and faculty training
Get a Quote
Request an itemised quotation covering the proposed configuration, availability, lead time and agreed supply and support scope.
Useful details to share
- Intended application, process or teaching activity
- Required capability and equipment it must work with
Share what you know. You can start with your name and a phone number or email; final specifications can follow.
Not sure which configuration you need? Help me choose
Contact Vvon Technologies Limited about EDIBON equipment requirements in Bangladesh.
Phone: +8801805987890 | Email: info@vvon.com.bd
