Gafchromic pnt-dos device
Brand: Ashland | Category: Medical Equipment
The pnt-dos device is the film element of the Gafchromic in-vivo dosimetry system: it is irradiated during the procedure and then read through the in-vivo dosimetry module of filmQA pro v8, letting dosimetry professionals verify that the dose was delivered as intended per device specifications. Under one inch long, half an inch wide and film thin, it reaches dose points in awkward places such as skin folds and sensitive areas around anatomy, and a light adhesive layer lets staff apply it to sloped surfaces once the plastic liner is peeled away, avoiding tape that can irritate skin. It is engineered to verify radiation doses in the low range below 80 cGy and the high range from 80 to 400 cGy. Every device carries a QR code holding serial number, expiration date and lot number, which is checked and recorded at each optical scan, and packages contain fifty measurement devices with three reference devices.
Selected manufacturer specifications
| Parameter | Value |
|---|---|
| Low-dose variant | Below 80 cGy |
| High-dose variant | 80–400 cGy |
| Package | 50 measurement devices and 3 reference devices |
| Attachment | Adhesive strip |
| Traceability | QR-based device and lot identification |
| Analysis configuration | FilmQA Pro v8 point-dose module, compatible scanner and calibration jig |
Ashland PNT-DOS device page. The two dose variants are separate selections. This is a secondary verification workflow, not a replacement for primary treatment planning or clinical dosimetry; confirm the complete validated package. Checked 2026-09-29.
Confirm your configuration
Share the details you know so we can prepare a comparable, itemised offer.
- Imaging modality or beam, energy range and intended QA test
- Phantom/dosimeter geometry, detector/readout compatibility and calibration needs
- Required test inserts, analysis software, certificates and acceptance criteria
Get a Quote
Request an itemised quotation covering the proposed configuration, availability, lead time and agreed supply and support scope.
Useful details to share
- Clinical, training or facility application
- Required configuration, accessories and existing equipment
Share what you know. You can start with your name and a phone number or email; final specifications can follow.
Not sure which configuration you need? Help me choose
Contact Vvon Technologies Limited about Ashland equipment requirements in Bangladesh.
Phone: +8801805987890 | Email: info@vvon.com.bd
