HTRC: Computer Controlled Experimental Reaction Turbine
Brand: EDIBON | Category: Scientific & Laboratory Equipment
HTRC is a computer controlled reaction turbine demonstration set. Water leaving the rotating arms produces the driving torque, and head, flow, speed and torque are logged so the reaction principle and machine efficiency can be studied.
Technical Specifications
| Parameter | Value |
|---|---|
| Dimensions | 600 x 400 x 450 mm approx |
| Weight | 30 Kg approx |
| Nozzle internal diameter | 1 mm |
| Turbine rotor external diameter | 69 mm |
| Turbine rotor internal diameter | 40 mm |
| Brake pulley diameter | 60 mm |
