inVia Reflex confocal Raman microscope
Brand: Renishaw | Category: Nanotechnology
inVia Reflex sits between the entry level inVia Basis and the fully automated inVia Qontor in Renishaw's confocal Raman microscope range. On top of the shared inVia spectrometer and research grade microscope it adds software microscope control, automatic switching between white light and Raman, automatic saving of the white light image with the data, combined white light and laser video viewing, and memorised automatic post collection viewing. An internal neon wavelength calibration source, internal reference standards for auto-calibration and a performance health check are included as well. LiveTrack automated focus tracking stays exclusive to the inVia Qontor model.
Confirm your configuration
Share the details you know so we can prepare a comparable, itemised offer.
- Sample type, measurement method and required spectral/time range
- Source/laser, detector, resolution, sample holder and optical interfaces
- Software, laser safety/site requirements, calibration and application training
Get a Quote
Request an itemised quotation covering the proposed configuration, availability, lead time and agreed supply and support scope.
Useful details to share
- Materials, sample dimensions and process or measurement goal
- Required performance and existing instrument interfaces
Share what you know. You can start with your name and a phone number or email; final specifications can follow.
Not sure which configuration you need? Help me choose
Contact Vvon Technologies Limited about Renishaw equipment requirements in Bangladesh.
Phone: +8801805987890 | Email: info@vvon.com.bd
