Jandel Hand Applied Probe
Brand: Jandel Engineering | Category: Nanotechnology
The Hand Applied Probe rests directly on the sample rather than being held above it, which avoids the reading drift seen with fully handheld methods. It measures thin layers, wafers and large ingots, but the strong downward force rules out fragile unsupported samples.
Technical Specifications
| Parameter | Value |
|---|---|
| Specification | Probe head loads up to 200 g per needle |
| Specification | Downward force of around 1.2 kg to compress the needles fully |
| Specification | Measures thin layers and wafers up to large ingots |
| Specification | Not suitable for fragile unsupported samples |
Get a Quote
Request an itemised quotation covering the proposed configuration, availability, lead time and agreed supply and support scope.
Useful details to share
- Materials, sample dimensions and process or measurement goal
- Required performance and existing instrument interfaces
Share what you know. You can start with your name and a phone number or email; final specifications can follow.
Not sure which configuration you need? Help me choose
Contact Vvon Technologies Limited about Jandel Engineering equipment requirements in Bangladesh.
Phone: +8801805987890 | Email: info@vvon.com.bd
