MSAC: Modular System for Acquisition and Control
Brand: EDIBON | Category: Scientific & Laboratory Equipment
A rack based acquisition and control system made up of a control interface box and interchangeable sensor modules. All sensor signals are conditioned to a -10 V to +10 V range and every actuator and sensor is handled from the computer during the whole test.
Technical Specifications
| Parameter | Value |
|---|---|
| Specification | Bench top unit with anodised aluminium frame and painted steel panels |
| Specification | MSAC/CIB Control Interface Box conditions all sensor signals to -10 V to +10 V |
| Specification | Sensor connectors have different pin counts, from 2 to 16, to prevent connection errors |
| Specification | Single cable between the control interface box and the computer |
| Specification | Simultaneous visualisation of all process parameters on the computer |
| Specification | Choice of PCIe or USB data acquisition board |
