MVL: Free Vibration Unit
Brand: EDIBON | Category: Scientific & Laboratory Equipment
MVL is a bench unit for studying the free vibration of beam and spring systems. Students measure the natural frequency and observe how amplitude decays with damping, comparing measured results with calculated values.
Technical Specifications
| Parameter | Value |
|---|---|
| Dimensions | 530 x 560 x 1030 mm approx |
| Weight | 25 Kg approx |
| Spring 1 | k = 3.30 kN/m |
| Spring 2 | k = 1.22 kN/m |
| Spring 3 | k = 0.47 kN/m |
| Specification | Five weights of 1 Kg each can be added and secured to the mass carriage |
