PBEAB: Pumps Alignment and Study Bench
Brand: EDIBON | Category: Scientific & Laboratory Equipment
PBEAB is a bench for teaching pump and motor shaft alignment. Angular and parallel misalignment is introduced deliberately and then corrected with dial gauges and shims, and its effect on vibration and running temperature is observed.
Technical Specifications
| Parameter | Value |
|---|---|
| Dimensions | 1215 x 270 x 1430 mm approx |
| Weight | 50 Kg approx |
| Specification | Conventional pump alignment system |
| Specification | Electrical control panel with digital display for speed and power monitoring |
Get a Quote
Request an itemised quotation covering the proposed configuration, availability, lead time and agreed supply and support scope.
Useful details to share
- Intended application, process or teaching activity
- Required capability and equipment it must work with
Share what you know. You can start with your name and a phone number or email; final specifications can follow.
Not sure which configuration you need? Help me choose
Contact Vvon Technologies Limited about EDIBON equipment requirements in Bangladesh.
Phone: +8801805987890 | Email: info@vvon.com.bd
