Recirculating Chillers
Brand: Lake Shore | Category: Nanotechnology
Lake Shore recirculating chillers provide closed-loop cooling water for electromagnets, power supplies, cryocoolers and measurement systems. Models are matched to the heat load of the system they serve, from 2,500 W single-phase up to 15,000 W three-phase. 50 Hz versions are also listed.
Technical Specifications
| Parameter | Value |
|---|---|
| LS2500-60-208230-1 | 2,500 W, 1-phase, 208 to 230 V |
| LS5000-60-208230-1 | 5,000 W, 1-phase, 208 to 230 V |
| LS7500-60-208230-3 | 7,500 W, 3-phase, 208 to 230 V |
| LS10000-60-208230-3 | 10,000 W, 3-phase, 208 to 230 V |
| LS15000-60-208230-3 | 15,000 W, 3-phase, 208 to 230 V |
| 50 Hz models | LS2200-50-200-1 and LS2200-50-230-1, 2,200 W, 1-phase |
Get a Quote
Request an itemised quotation covering the proposed configuration, availability, lead time and agreed supply and support scope.
Useful details to share
- Materials, sample dimensions and process or measurement goal
- Required performance and existing instrument interfaces
Share what you know. You can start with your name and a phone number or email; final specifications can follow.
Not sure which configuration you need? Help me choose
Contact Vvon Technologies Limited about Lake Shore equipment requirements in Bangladesh.
Phone: +8801805987890 | Email: info@vvon.com.bd
