SGCM: Unit to Study a Spur Gear Cutaway Model
Brand: EDIBON | Category: Scientific & Laboratory Equipment
This mitre gear is the Unit to Study a Spur Gear Cutaway Model, "SGCM", designed by EDIBON.
Published teaching-model details
| Parameter | Value |
|---|---|
| Output cogwheel teeth | 68 |
| Drive pinion teeth | 24 |
| Unit dimensions | 350 × 300 × 200 mm approx. |
| Unit weight | 11 kg approx. |
Selected construction and installation values for the SGCM cutaway teaching model from brochure pages 2–4. This is a model for observing a transmission mechanism; the data does not establish suitability as an industrial production drive. Confirm the complete teaching set and safety instructions. Checked 2026-09-29.
