SOM® 62 Ophthal Basic
Brand: Karl Kaps | Category: Medical Equipment
A compact surgical microscope for general eye surgery, the Ophthal Basic is built for practices and smaller clinics that want dependable optics without additional complexity. The five-position apochromatically corrected magnification changer switches between overview and detail without sacrificing stereoscopic vision. Coaxial cold light fibre optic illumination rated 15V/150W produces the bright red reflex that reveals every layer of the retina, and a ready-to-use spare lamp is built in. Patient safety is covered by the swing-in GG 475 retina protection filter with permanently installed IR and UV filters, and the motorised 40 mm fine focus is driven from a foot switch.
Selected manufacturer specifications
| Parameter | Value |
|---|---|
| Magnification changer | 5-position apochromatic |
| Objective | f = 200 mm |
| Binocular tube | 60° inclined, f = 159 mm |
| Motorised fine-focus travel | 40 mm |
| Illumination | 15 V / 150 W coaxial cold light |
Selected details from the named Karl Kaps product page. Optical performance and compatibility depend on the chosen objectives, eyepieces, illumination and mounting. Optional equipment is not included unless specified in the quotation. Checked 2026-09-29.
