TTLFB: Fluidization and Fluid Bed Heat Transfer Unit
Brand: EDIBON | Category: Scientific & Laboratory Equipment
Lit glass chamber holding a granular bed through which air is supplied from below. It shows the change from a packed bed to a fluidised bed and lets students measure heat transfer in the bed at different heights and air velocities.
Technical Specifications
| Parameter | Value |
|---|---|
| Specification | Nine different distributors with varying number, size and distribution of orifices |
| Specification | Two types of granular material of different size supplied to form the bed |
| Specification | Heating element and sensors for inlet air, outlet air, bed and element surface temperature |
| Specification | Heating element and bed sensors can be moved vertically in the chamber |
| Specification | U shaped manometer determines the pressure drop across the bed |
| Specification | Inlet regulation valve and flow meters for the air supply |
