TFLVB: Laminar/Viscous Flow Heat Transfer Unit
Brand: EDIBON | Category: Scientific & Laboratory Equipment
Concentric tube exchanger in which hot oil flows in laminar regime through the inner tube while cold water flows through the annulus. Students carry out energy balances, determine film and overall heat transfer coefficients and calculate the Reynolds number.
Technical Specifications
| Parameter | Value |
|---|---|
| Specification | Closed hot oil circuit with heating tank, pump, flow meter and regulation valve |
| Specification | Oil flow adjustable by pump speed potentiometer and by a bypass regulation valve |
| Specification | Cold water circuit with regulation valve and flow meter |
| Specification | Co-current or counter-current operation selected by valves |
| Specification | Purge valve to drain and clean the oil circuit and heating tank |
| Specification | Computer controlled version available as TFLVC |
