Violet stimulation attachment
Brand: Riso | Category: Scientific & Laboratory Equipment
A violet laser stimulation option for the Riso TL/OSL reader, fitted in the same style of head as the single grain attachment. It comes with matched stimulation and detection filters, and its driver electronics sit inside the reader controller.
Technical Specifications
| Parameter | Value |
|---|---|
| Specification | 405 nm, 100 mW laser module |
| Specification | Stimulation filters ITOS GG395 (3 mm) and AHF F49-402 ET bandpass 402/15 nm |
| Specification | Detection filter Semrock Brightline FF01-340/26 |
| Specification | Driver electronics built into the controller |
| Specification | Cannot be used at the same time as any single grain system |
