AMT: Pipe Network Unit, with Hydraulics Bench (FME00)
Brand: EDIBON | Category: Scientific & Laboratory Equipment
AMT is a pipe network for studying flow distribution in looped and branched systems. Valves isolate each branch while flow and head loss are measured, so the Hardy Cross method can be applied. Computer controlled and standalone versions, AMTC and AMT/P, are also published.
Technical Specifications
| Parameter | Value |
|---|---|
| Dimensions | 1500 x 1000 x 1700 mm approx |
| Weight | 100 Kg approx |
| Specification | Aluminum pipe, 16 mm outer diameter |
| Specification | PVC pipe, 25 mm outer diameter |
| Specification | PVC pipe, 16 mm outer diameter |
| Specification | PVC pipe, 20 mm outer diameter |
Get a Quote
Request an itemised quotation covering the proposed configuration, availability, lead time and agreed supply and support scope.
Useful details to share
- Intended application, process or teaching activity
- Required capability and equipment it must work with
Share what you know. You can start with your name and a phone number or email; final specifications can follow.
Not sure which configuration you need? Help me choose
Contact Vvon Technologies Limited about EDIBON equipment requirements in Bangladesh.
Phone: +8801805987890 | Email: info@vvon.com.bd
