ARM Fiber Laser
Brand: Coherent | Category: Scientific & Laboratory Equipment
ARM fibre lasers use an adjustable ring mode beam with a centre beam and a coaxial ring beam under independent power and modulation control. That control suits welding of heat sensitive materials, dissimilar materials, cast aluminium and copper.
Technical Specifications
| Parameter | Value |
|---|---|
| ARM FL | 2 to 10 kW, multi-mode centre beam, detachable fiber, FFC or FFS |
| ARM FL D | 6 to 20 kW, multi-mode centre beam, detachable fiber, FFC or FFS |
| ARM FL Compact | 2 to 10 kW, single-mode or multi-mode centre beam, spliced fiber |
| ARM FL 4000CSM | 4 kW, single-mode centre beam, spliced fiber |
| Specification | Newer model adds an independently controlled centre beam with two separate coaxial ring beams |
Get a Quote
Request an itemised quotation covering the proposed configuration, availability, lead time and agreed supply and support scope.
Useful details to share
- Intended application, process or teaching activity
- Required capability and equipment it must work with
Share what you know. You can start with your name and a phone number or email; final specifications can follow.
Not sure which configuration you need? Help me choose
Contact Vvon Technologies Limited about Coherent equipment requirements in Bangladesh.
Phone: +8801805987890 | Email: info@vvon.com.bd
