C-Series Photodiode Power Sensors (S100 Series)
Brand: ThorLabs | Category: Scientific & Laboratory Equipment
Photodiode sensor heads for optical power meter consoles, chosen when fast response and high resolution matter more than a flat spectral response. Standard, slim, microscope slide, integrating sphere and fibre versions all share the C-Series connector.
Technical Specifications
| Parameter | Value |
|---|---|
| Specification | Power ranges covering 100 pW to 20 W |
| Specification | Wavelength ranges covering 200 nm to 5.5 micrometres |
| S120C silicon head | 400 to 1100 nm, 50 nW to 50 mW, resolution 1 nW |
| Linearity | plus or minus 0.5% |
| Measurement uncertainty | plus or minus 3% from 440 to 980 nm |
| Specification | Individually calibrated with a NIST or PTB traceable certificate |
Get a Quote
Request an itemised quotation covering the proposed configuration, availability, lead time and agreed supply and support scope.
Useful details to share
- Intended application, process or teaching activity
- Required capability and equipment it must work with
Share what you know. You can start with your name and a phone number or email; final specifications can follow.
Not sure which configuration you need? Help me choose
Contact Vvon Technologies Limited about ThorLabs equipment requirements in Bangladesh.
Phone: +8801805987890 | Email: info@vvon.com.bd
