CPX Cryogenic Probe Station
Brand: Lake Shore | Category: Nanotechnology
The CPX is a cryogenic probe station built around a split flow cryostat with independent flow control of the sample and the radiation shields. Sample temperatures reach 1.6 K with the PS-VLT-CPX option, with control up to 475 K. It is used for electrical measurements on devices and materials at low temperature.
Technical Specifications
| Parameter | Value |
|---|---|
| Base temperature | 4.3 K with up to 6 probe arms installed, control range 4.4 K to 475 K |
| Base temperature | 1.9 K with the PS-LT option, control range 2 K to 475 K |
| Base temperature | 1.6 K with the PS-VLT-CPX option, control range 1.65 K to 420 K |
| Cryostat | 1 + 3-stage split flow cryostat (sample plus 3 radiation shields) with independent flow control of sample and shields |
| Magnetic field | ring magnet kit |
| Cycle time (LHe) | 3 h |
