Discovery V
Brand: Denton Vacuum | Category: Nanotechnology
A planar cathode magnetron sputtering module designed to run on the Versa cluster platform. The cathode sits directly above the substrate, which gives tight uniformity in film thickness, sheet resistance and refractive index across one side of the wafer.
Technical Specifications
| Parameter | Value |
|---|---|
| Cathode | 300 mm planar cathode |
| Substrate size | standard applications up to 200 mm wafers |
| Specification | Adjustable rotating magnet pack for uniformity optimisation |
| Specification | Designed for integration on the Versa cluster platform |
| Applications | thin film resistors and sensors, wafer metal and dielectric films, metal contacts of compound semiconductors |
Get a Quote
Request an itemised quotation covering the proposed configuration, availability, lead time and agreed supply and support scope.
Useful details to share
- Materials, sample dimensions and process or measurement goal
- Required performance and existing instrument interfaces
Share what you know. You can start with your name and a phone number or email; final specifications can follow.
Not sure which configuration you need? Help me choose
Contact Vvon Technologies Limited about Denton Vacuum equipment requirements in Bangladesh.
Phone: +8801805987890 | Email: info@vvon.com.bd
