EPLED Series: Picosecond Pulsed LEDs
Brand: Edinburgh Instruments | Category: Nanotechnology
Pulsed LED sources reaching into the deep ultraviolet from 250 nm, where diode lasers are not available, with sub-nanosecond pulse widths for lifetime measurement. The series runs from 250 nm to 610 nm and shares the housing, trigger interface and mounting of the EPL diode lasers.
Model specifications
Compare the named models or configurations. Confirm options and included accessories in your quotation.
| Model (EPLED-) | Wavelength (± 10 nm) | Typical Pulse Width (FWHM) (ps) | Maximum Pulse Width (FWHM) (ps) |
|---|---|---|---|
| 250 | 250 | 900 | 950 |
| 255 | 255 | 900 | 950 |
| 260 | 260 | 850 | 950 |
| 265 | 265 | 850 | 950 |
| 270 | 270 | 900 | 950 |
| 280 | 280 | 900 | 950 |
| 295 | 295 | 1000 | 1150 |
| 300 | 300 | 1000 | 1150 |
| 310 | 310 | 910 | 980 |
| 320 | 320 | 880 | 950 |
| 340 | 340 | 1050 | 1300 |
| 365 | 365 | 900 | 950 |
| 380 | 380 | 990 | 1050 |
| 560 | 563 | 1500 | 1750 |
| 570 | 572 | 1350 | 1600 |
| 590 | 590 | 1300 | 1600 |
| 610 | 610 | 1250 | 1400 |
Manufacturer catalogue checked 2026-09-29.
Each row identifies a separate wavelength model. Typical, maximum and minimum values and the stated repetition-rate conditions are retained in the column headings. Select the exact wavelength, optical output and trigger configuration against the complete current datasheet.
