Helmholtz Coils (Field Standards)
Brand: Lake Shore | Category: Nanotechnology
These Helmholtz coils generate a known, uniform magnetic field from an applied current, so they can be used to calibrate and check magnetic field sensors. Single-axis coils are offered in 2.5 in, 6 in and 12 in inside diameters, along with a 2-axis model. Field accuracy is 0.75%.
Technical Specifications
| Parameter | Value |
|---|---|
| Models | MH-2.5, MH-6, MH-12, MH-2X-10 |
| Field accuracy | 0.75% |
| Inside diameter | 2.5 in, 6 in, 12 in, and 12 in (x-axis) with 9.75 in (y-axis) |
| Field strength | approximately 30 G/A (MH-2.5), 25 G/A (MH-6), 13 G/A (MH-12), 15 G/A (MH-2X-10) |
| Maximum continuous current | 2 A (DC or RMS) |
| Operating temperature range | 0 °C to 40 °C (32 °F to 104 °F) |
