Helmholtz Coils (Moment Measurement)
Brand: Lake Shore | Category: Nanotechnology
These Helmholtz coils work with the Model 480 fluxmeter to measure the magnetic moment of permanent magnets and magnet assemblies. The sample sits at the centre of the coil pair and the flux change is integrated by the fluxmeter. Single and 2-axis configurations are available.
Technical Specifications
| Parameter | Value |
|---|---|
| Models | FH-2.5, FH-6, FH-12 |
| Calibration accuracy | 0.75% |
| Inside diameter | 2.5 in, 6 in, 12 in |
| Coil resistance (approx) | 35 Ω (FH-2.5), 110 Ω (FH-6), 140 Ω (FH-12) |
| Coil constant (approx) | 0.013 Wb·cm/V·s (FH-2.5), 0.016 Wb·cm/V·s (FH-6), 0.047 Wb·cm/V·s (FH-12) |
| Operating temperature range | 0 °C to 60 °C |
