High Voltage Amplifier and Sample Holder
Brand: Nanosurf | Category: Nanotechnology
A ten times voltage amplifier with a matching sample holder for piezoelectric force microscopy. It takes the fixed plus or minus 10 V output of the controller and delivers plus or minus 100 V to the sample, which is what stiff ferroelectric materials need to switch.
Technical Specifications
| Parameter | Value |
|---|---|
| Input voltage range | plus or minus 10 V, fixed |
| Output voltage range | plus or minus 100 V |
| Amplification | x10 |
| Maximum current | 0.57 A |
| Dimensions | 275 x 141 x 64 mm, weight 1 kg |
| Compatibility | DriveAFM, FlexAFM, CoreAFM |
