InAs and GaAs Hall Sensors
Brand: Lake Shore | Category: Nanotechnology
InAs and GaAs Hall sensors are supplied as bare sensing elements in axial and transverse packages for measuring magnetic flux density. Types range from general purpose parts to instrumentation quality sensors with low temperature coefficients. They are used with Lake Shore 400 Series gaussmeters.
Technical Specifications
| Parameter | Value |
|---|---|
| Axial sensor models | HGA-2010, HGA-2302, HGA-2303, HGA-3010, HGA-3030 |
| Transverse sensor models | HGT-1010, HGT-1020, HGT-2010, HGT-2101, HGT-3010, HGT-3030 |
| Nominal control current | 1 mA or 100 mA |
| Operating temperature range | -20 °C to +75 °C, or -40 °C to +100 °C |
