ITC4000 Series Combined Laser Diode and TEC Controllers, 5 A to 20 A
Brand: ThorLabs | Category: Scientific & Laboratory Equipment
Single instruments that combine a high current laser diode driver with a 225 W thermoelectric controller. A 20 V compliance version drives quantum cascade and interband cascade lasers, and digital PID with auto tuning holds the diode temperature steady.
Technical Specifications
| Parameter | Value |
|---|---|
| Laser diode current range | 0 to 5 A (ITC4005) or 0 to 20 A (ITC4020) |
| Compliance voltage | 12 V, 20 V on the ITC4005QCL, 11 V on the ITC4020 |
| TEC current range | -15 A to 15 A with more than 225 W output power |
| Temperature stability | 0.002 degrees C over 24 hours |
| Specification | QCW pulse widths down to 100 microseconds, repetition rates up to 1 kHz |
| Specification | Internal or external analogue modulation to 100 kHz small-signal bandwidth |
Get a Quote
Request an itemised quotation covering the proposed configuration, availability, lead time and agreed supply and support scope.
Useful details to share
- Intended application, process or teaching activity
- Required capability and equipment it must work with
Share what you know. You can start with your name and a phone number or email; final specifications can follow.
Not sure which configuration you need? Help me choose
Contact Vvon Technologies Limited about ThorLabs equipment requirements in Bangladesh.
Phone: +8801805987890 | Email: info@vvon.com.bd
